granule packing machine

Introduction:
Granule quantitative packing machine adopts gravity type material feeding,it is mainly composed of host machine, weighing device, PLC and hoist, etc. The whole machine can be made of carbon steel or half stainless steel(only material contact part use stainless steel).

Application:
Suitable for packing lentils, rice, millet, beans, peas, buckwheat, green beans, corn millet, barley, sweet, pea, adzuki bean, seeds, fertilizer, sugar, fodder, feedstuffs, corn, Leisure food, hardware, salt, MSG, chicken essence, pesticide, fertilizer, rice, veterinary medicine, feed premix, additives, biomass particle, detergent powder etc.
granule packing machine
  • Model: DCS-YB5
  • Power:0.6KW
  • Weight: 300kg
  • Precision: ±0.2%FS
  • Weighing Range: 50g-2000g
  • Packing Speed: 480-720 bags/hour
  • Air Source Pressure: 0.4-0.6Mpa
  • Dimension: 600*600*1850mm
  • Electrical Power: AC380/220,50/60(V/Hz), 3/1 phase, made as per requirement
  • Packaging container: Aluminum foil bag, plastic bag, paper bag, bottle, etc
granule packing machine
  • Model: DCS-YB25
  • Weighing Range:10kg-50kg
  • Packing Speed: 120-240 bags/hour,360-420 bags/hour
  • Precision: ±0.2%FS
  • Power:1KW
  • Electrical Power: AC380/220,50/60(V/Hz), 3/1 phase, made as per requirement
  • Air Source Pressure: 0.4-0.6Mpa
  • Weight:600kg
  • Dimension: 2200*800*2600 mm
  • Length of belt conveyor: 2200mm
  • Width of belt conveyor: 300mm
granule packing machine
  • Model: DCS-YB50
  • Weighing Range:20kg-80kg
  • Packing Speed: 480-720 bags/hour
  • Precision: ±0.2%FS
  • Power:1.5KW
  • Electrical Power: AC380/220,50/60(V/Hz), 3/1 phase, made as per requirement
  • Air Source Pressure: 0.4-0.6Mpa
  • Weight: 1200kg
  • Dimension: 3000*1000*3300 mm
  • Length of belt conveyor: 3000mm
  • Width of belt conveyor: 400mm
